Cetco Aquadrain ICD Membrane 20mm - 2 x 20m Roll

AQUADRAIN ICD 20mm is a robust cavity drain membrane engineered for both walls and floors in demanding waterproofing applications. The high-density polyethylene (HDPE) core features 20mm deep studs, creating an extensive drainage void to manage significant water ingress. When installed on floors and overlaid with concrete, the membrane’s high point load resistance (150 kN/m²) allows for the construction of load-bearing walls directly on the slab. Its integrated flat flange ensures secure overlapping and easy installation.

Uses & Applications

• Heavy-Duty Drainage: Ideal for walls and floors in extremely wet conditions where superior drainage capacity is required.
• Floor Applications: Typically installed without the need for perimeter drainage channels, simplifying the waterproofing system.
• Load-Bearing Support: The large stud profile, when overlaid with concrete, provides excellent structural support for walls built on the slab.
• Enhanced Thermal Insulation: The increased cavity depth improves insulation values, contributing to energy efficiency.

Advantages

• The highest drainage void volume in the AQUADRAIN ICD range (14 litres/m²) for superior water management.
• Exceptional compressive strength (150 kN/m²) to support structural loads.
• Compatible with both dry lining and wet plaster finishes, offering flexible installation options.
• Manufactured from high-quality, durable HDPE for long-term performance.

Packaging

Supplied in rolls of 2.0m x 20m (including a flat overlapping flange), covering an effective working area of approximately 40m².
